FLOAT answers the demands of the modern trail rider; a firm pedal platform for uphill efficiency and confidence-inducing, trail-hugging descent capability, all in a lightweight package. Trail riders seek a shock with the performance of a Float X but with lightweight capability like that found in the Float SL. Yet there is nothing middle-of-the-road about FLOAT. With its large volume EVOL air spring, riders can run their shock at lower air pressures for a more linear feel throughout the stroke. This results in smoother small bump performance, better grip at the tires and a shock that will not overheat on the demanding descents.
- Factory models are feature-packed and designed to exceed the demands of Factory-level riders with slippery smooth, ultra-durable Genuine Kashima Coat
- Optimized suspension for trail riding - firm platform for pedaling and climbing efficiency without penalizing descending performance
- New large diameter main piston, valving, and IFP for increased performance, consistency, and tuneability
- Lightweight, one-piece EVOL air sleeve improves responsiveness and sensitivity
- MCU bottom-out bumper for end-stroke progressivity
- Open, Medium and Firm modes of compression adjustment
- Adjustable rebound and air spring pressure
| Item Specifications |
| External Adjustments |
High Speed Compression Damping |
| External Adjustments |
Low Speed Compression Damping |
| External Adjustments |
Rebound Damping |
| Eye to eye length (mm) |
185 |
| Eyelet Diameter (mm) |
Trunnion, 12.7 |
| keyword search |
FOX Model Year 25 |
| keyword search |
FOX MY25 |
| Lockout Switch |
Shock Mounted Switch |
| Metric |
Yes |
| Positive Spring |
Air |
| Stroke (mm) |
50 |
